HF6.XXX
LEVEL AND PRESSURE TRANSMITTER
PVDF Body Level/Pressure Hydrostatic Transmitter
FLS HF6 is a new family
of transmitters suitable
for hydrostatic level/depth
measurement and for pressure
monitoring.
PVDF body and ceramic
diaphragm with FPM
sealing system offer a smart
combination of valuable wetted
materials.
The semi-flush diaphragm can
work properly and for long time
in pasty media and with liquids
tending to crystallize.
HF6 family can be also the
finest choice for clean water
applications in case customer
would maximize operating
time.
The compact design can fit
all main applications related
to aggressive and corrosive
liquids granting different
solutions of installation: screwin
(combined with a FIP valve
or fitting), submersed with
PUR cable running into pipe
and submersed with PUR/FEP
cable in contact with liquid.
Other operating ranges and
selectable length of cable in
addition to sealing material
options offer a customized
solution to match the customer
needs in the best possible way.
| Objednací číslo | Materiál | Kategorie | Série | product.detail.attribute.Applications/ Operative Range | product.detail.attribute.Process connection | product.detail.attribute.Main Wetted Materials | product.detail.attribute.Measuring Mode | product.detail.attribute.Diaphragm | product.detail.attribute.Cable | product.detail.attribute.Weight (gr.) (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| HF6.004 | FLS Measurement Instrumentation | FLS systém pro měření a regulaci | HF6 | 0-400 mbarg | STD: ¾" G (A class) SUBMERSED: ½" R (A class) | PVDF $ PUR $ FKM $ Ceramic | Relative Pressure | Ceramic $ Semi flush | PUR 8 m | 550 |
| HF6.010 | FLS Measurement Instrumentation | FLS systém pro měření a regulaci | HF6 | 0-1000 mbarg | STD: ¾" G (A class) SUBMERSED: ½" R (A class) | PVDF $ PUR $ FKM $ Ceramic | Relative Pressure | Ceramic $ Semi flush | PUR 8 m | 550 |
| HF6.100 | FLS Measurement Instrumentation | FLS systém pro měření a regulaci | HF6 | 0-10 barg | STD: ¾" G (A class) SUBMERSED: ½" R (A class) | PVDF $ PUR $ FKM $ Ceramic | Relative Pressure | Ceramic $ Semi flush | PUR 8 m | 550 |
| HF6.160 | FLS Measurement Instrumentation | FLS systém pro měření a regulaci | HF6 | 0-16 barg | STD: ¾" G (A class) SUBMERSED: ½" R (A class) | PVDF $ PUR $ FKM $ Ceramic | Relative Pressure | Ceramic $ Semi flush | PUR 8 m | 550 |
- APPLICATIONS • Storage Tank management • Liquid inventory control • Over flow detection • Water/Wastewater monitoring • Chemicals processing • Tank farm management • Water recycling MAIN FEATURES • Level/Pressure/Depth measurement providedby the same transmitter • Level measurement not affected by foam or vapour • Premium combination of wetted materials • Semi flush ceramic diaphragm for a long-lasting operating time • Options for gauge pressure and for absolute pressure • Flexible submersible installation (with or without conduit) • Other operating ranges available on request:full scale @ 600mbar, 1600mbar, 2500mbar, 4000mbar,6000mbar, 25bar, 40bar (gauge or absolute mode).
